Drill Spacer 15422198 C190000845006 Hydraulic Rock Drill Alignment Component for Underground Mining

Part Number: 15422198 C190000845006

Material: Nitrided alloy steel (tensile strength ≥1100 MPa, HV 550 surface hardness)

Dimensions:

Length: 150 mm (ISO 1133 H7 tolerance)

Outer Diameter: 80 mm

Inner Diameter: 60 mm

Weight: 3.5 kg (estimated based on similar hydraulic spacers)

Pressure Rating: 300 bar (continuous operation)

Compatibility: Direct fit for Sandvik hydraulic rock drill models requiring precise axial alignment

Mounting: M24 x 2.0 threaded ports (ISO 7-1 compliant)
